Rolling Shutter & Gate Profile Forming Line
Watch Video
Technical
Specifications
Compare
Coil width (mm)
125
Coil thickness (mm)
0.8-1.2
Roll Shaft Dia. (mm)
50
Horizontal distance b/w stations (mm)
280
Vertical distance b/w stations (mm)
120
Max. Profile Height (mm)
15
Required Power (H.P.)
5
Line Speed (mpm)
20 Feet / Minute
Product
Features
Embossed pattern available
hydraulic cut off die to cut profile
Previous
C & Z Purlin Forming Line
Next
Roofing Sheet Gate Profile Forming Line
Road Building & Infra Projects
Solar Structure Profiling Line
Cold Room Sandwich Panel Forming Line
Highway Guard Rail & w beam Roll Forming Line
Stud & Track Forming Line
Cable Tray & Trunking profile line
C & Z Purlin Forming Line
Rolling Shutter & Gate Profile Forming Line
Roofing Sheet & Wall cladding Roll Forming Line
Coil width (mm)
100-500
500 to 1250
300-750
300
500-1000
400
125
1250-1450
Coil thickness (mm)
1.2-3.15
Up to 0.8
Up to 5
Up to 0.8
Up to 2.5
Up to 3.5
0.8-1.2
Up to 0.63mm for Roofing sheet
Roll Shaft Dia. (mm)
70
75
85
40
85
70
50
85
Horizontal distance b/w stations (mm)
400
250
530
200
500
427
280
550
Vertical distance b/w stations (mm)
202
140
198
115
225
270
120
150
Max. Profile Height (mm)
70
20
85.5
35
100
85/100
15
35
Required Power (H.P.)
30
20
50
7.5
40
20
5
15
Line Speed (mpm)
10-30
10-15
12
Up to 30
Up to 30
5-18
20 Feet / Minute
12 to 15
